QU50680 Timken® Taper Roller Bearing for NP200, NP201, Vintage Wheel Bearing

QU50680 Timken® Taper Bearing is most commonly used in 4×4 transfer case and wheel bearing applications. This is a First Class, original equipment quality bearing that meets or exceeds all vehicle manufacturer specifications making it the top choice for heavy-duty applications like yours. Country of origin may vary as Timken produces Bearings in plants located around the globe, however QU50680 is almost always made in either Canada or the United States.

Need More Info? Use the handy Links below to access over 40 years of Dan’s product and vehicle specific Tech Notes to easily get the information you need for your vehicle’s repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
Always Replace
Matching Bearing Cup
Matching Parts for NP200 & NP201
Matching Parts for IHC Dana 70 Front
Applications

Tech Note 1: Always Replace
Always replace the cup and cone at the same time.

Tech Note 2: Matching Bearing Cup
The matching bearing cup for most 4×4 Wheel Bearing and New Process Transfer Case applications is QU50705.

Tech Note 3: Matching Parts for NP200 & NP201
Matching Parts for NP200 and NP201 Transfer Cases:
QU50705 Rear Output Shaft, Inner Bearing Cup
TK50347 Rear Output Shaft Outer Bearing Cone
TK50346 Rear Output Shaft Outer Bearing Cup
TKA2053 Output Shaft Shim Kit
TK2110 Premium NP200 Bearing and Seal Kit
QU50515 NP201 Bearing and Seal Kit
TK2048 Premium NP201 Bearing and Seal Kit
TK2112 NP200 Gasket Kit
TK10503 5 Bolt Rear Output Gasket
TK10604 8 Bolt Rear Housing Gasket
TK50123 Output Seal
QK2036 Output Shaft Nut and Washer Set

Tech Note 4: Matching Parts for IHC Dana 70 Front
Matching Parts for 1961-1968 IHC Dana 70 Front Axles:
QU50403 Timken Inner Wheel Bearing
QU50402 Timken Inner Wheel Bearing Cup
QU50705 Timken Outer Wheel Bearing Cup
QU50645 Wheel Seal
QU15006 6 Bolt Hub Gasket
QU90018 Pyroplex Synthethic Grease

Applications

Dodge, Plymouth, Ram, Sterling:
Transfer Case Rear Output Shaft Inner Bearing:
All WM300 and Military M37 Series with New Process NP200 Transfer Case: 1946, 1947, 1948, 1949, 1950, 1951, 1952, 1953, 1954, 1955, 1956, 1957, 1958, 1959, 1960, 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968
W100, W200, W300 with New Process NP200 or NP201 Transfer Cases: 1957, 1958, 1959, 1960, 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968

International:
Front Outer Wheel Bearing:
1 Ton C130, D130, and 1300 Series 4×4 with FA52 Dana 70 Front Axle: 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968
Transfer Case Rear Output Shaft Inner Bearing:
All 4×4 with New Process NP200 or NP201 (T-140) Transfer Cases: 1955, 1956, 1957, 1958, 1959, 1960

Jeep:
Transfer Case Rear Output Shaft Inner Bearing:
Military M3715, M725, M726 Series New Process NP200 Transfer Case: 1967, 1968, 1969
