QU50038 CV Flange Yoke Liner for Saginaw or AAM CV Flanges

QU50038 CV Flange Yoke Liner for Saginaw or AAM S44, 3R, 1344, and 1350/1355 series Double Cardan Constant Velocity Flange Yokes. Liner presses into your CV Flange Yoke to replace worn or dented liners. USA Made.

Also see QA40752 CV Centering Kit.

Need More Info? Use the handy Links below to access over 40 years of Dan’s product and vehicle specific Tech Notes to easily get the information you need for your vehicle’s repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
Product Note
Applications

Tech Note 1: Product Note
Saginaw Double Cardan CV driveshafts were used by Chevy, Dodge, Ford, and GMC. The Yoke Liner is a simple press fit in the cast iron CV Flange Yoke. Just press or drive out the old one and press/drive in the new one until it seats.

Applications:

Chevy/GMC:
All full size 4×4 with square body style: 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991

Dodge:
Ramcharger, W-110, W-150, W-200, W-250, W300, W-350 4×4 trucks: 1975.5, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993

Ford:
Super Duty 4×4 (some): 1999, 2000, 2001, 2002
Excursion 4×4 (some): 2000, 2001, 2002

Plymouth:
Trailduster
