QU40022 Dana 60, Dana 70 Pinion Nut

QU40022 Dana 60, Dana 70 Pinion Nut Genuine Dana-Spicer all-metal, prevailing torque type lock nut is the original equipment replacement part for most Dana-Spicer Model 60, 61, 70, and 70HD front and rear axles. Use 1-5/16″ socket. Country of origin unknown.

Need More Info? Use the handy Links below to access over 40 years of Dan’s product and vehicle specific Tech Notes to easily get the information you need for your vehicle’s repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
Designed to Use Once
Related Parts
Matching Parts
Applications

Tech Note 1: Designed To Use Once
Prevailing Torque Self-Locking Pinion Nuts are designed to be used only once as they lose some of their resistance to backing off every time they are removed. Always install a new lock nut on your axle when doing final assembly.

Tech Note 2: Related Parts
For related parts see: Universal Joints TK40722 or QU40775; Strap and Bolt Kit for U-Joint QU40763; Pinion Yoke QU40747; Pinion Nut QU40009; Pinion Washer QU40023; Pinion Seal QU40097; Pinion Slinger (between Yoke and Inner Bearing) QU40002. For 1994-1999 Rams see QU40356 for the collapsible pinion preload spacer (crush sleeve).

Tech Note 3: Matching Parts
Exploded View XV1001 1975-1989 Dodge W250, W350 Dana 60/61 Front Axle
Exploded View XV1006 1977-1991 Chevy & GMC Dana 60 Front Axle
Exploded View XV1004 1990-1993 Dodge W250, W350 Dana 60/61 Front Axle
Exploded View XV1015 1985-1991 Ford F350 Dana 60 Front Axle
Exploded View XV1013 1992-1994 Ford F350 Dana 60 Front Axle
Exploded View XV1011 1995-1997 Ford F350 Dana 60 Front Axle
Exploded View XV2006 1994-1999 Dodge Ram 2500 Dana 60 Rear Axle
Exploded View XV2009 2000-2002 Dodge Ram 2500 Dana 60 Rear Axle

Applications
Chevrolet, Dodge, Ford, GMC, International, and Jeep vehicles-Just about all Dana-Spicer Model 60, 61, 70, and 70HD axles from the 1950’s, 1960, 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968, 1969, 1970, 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018
