QU20102 1350 Series Pinion Yoke 1993-1997 Ford Sterling 10.5″ Rear Axle

QU20102 1350 Series Ford Sterling 10.25″ Rear Axle Pinion Yoke for 1993-1997 Diesel and 460 trucks This yoke takes u-joints with 1-3/16″ diameter cups which are held in place by optional QU40709 U-joint Strap and Bolt Kit (The Yoke holes are threaded). Length of pinion spline is approximately 1-41/64″. Imported. For 1993 to 1997 Ford small engine trucks using Yokes with unthreaded holes, see QU20101.

Also See: QU20102U Used 1350 Series Rear Pinion Yoke available while supplies last.

Need More Info? Use the handy Links below to access over 40 years of Dan’s product and vehicle specific Tech Notes to easily get the information you need for your vehicle’s repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
U-Joint Specs
Yoke Specs
Matching Parts
Applications

Tech Note 1: U-Joint Specs
QU20102 yoke is made to take universal joints made to Spicer 1350 series external snap ring universal joint specifications. Your u-joint cup diameter should be 1-3/16″ and the overall width of the universal joint should be 3-5/8″. See TK40719 and QU40731 External Snap Ring Universal Joints.

Tech Note 2: Yoke Specs
This 31 spline yoke has a length through the hole of 1-41/64″ so it will fit late 10.25″ rear axles, but it will not fit early (1985-1992) 10.25″ short pinion Ford axles. See QU20028 for a short spline Pinion Yoke.

Tech Note 3: Matching Parts
When replacing an old pinion yoke, always replace the pinion seal, pinion nut, and crush sleeve. Replace the u-joint strap kit and outer pinion slinger as needed. Order these matching parts separately:
QU40709 U-joint Strap and Bolt Kit
QU20050 Pinion Seal
QU20002 Pinion Nut
QU20003 Outer Pinion Slinger
QU20000 Crush Sleeve

Applications
Ford:
Ford F-250, F-350 with Diesel or 460 engines 1993, 1994, 1995, 1996, 1997
