QK4685 Front Inner Axle Seal and Tool Kit 2003-13 Ram AAM 925 14 Bolt

QK4685 Front Inner Axle Seal Installer Kit for 2003-2013 Dodge Ram AAM 9-1/4″ 14 Bolt Front Axles installs the Inner Axle Seals on 2003-2013 AAM 925 14 Bolt front beam axles used in all 2003-2013 Ram 2500, 2003-2012 Ram 3500 4×4 trucks. Also fits 2004-2010 Ram 1500 Mega Cab with the solid beam 4×4 front axle. Precision CNC made installation tools are specifically made to quickly and easily install the included QU10945 Genuine AAM Axle Seals to the correct depth without damaging, cocking, or crushing the rather delicate seals or your Axle Adjuster Threads which are machined in the housing. Our QK4685 Kit makes inner axle oil seal installation easy and almost fool-proof on your Dodge Ram 4×4 equipped with the AAM 9-1/4″ 14 Bolt front axle! Tools Made in Montana.

Also See TS4685 Axle Seal Installer Tool Set without Seals

Need More Info? Use the handy Links below to access over 40 years of Dan’s product and vehicle specific Tech Notes to easily get the information you need for your vehicle’s repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
Includes
Must Remove
Seal Type
After Installing
2003-2013.5
2013.5-Current
Applications

Tech Note 1: Includes
QK4685 Kit includes:
QT1143 Seal Installer
QT1193 Thrust Plate
TS1195 Press Screw Assembly
(2) QU10945 Seals

Tech Note 2: Must Remove
To replace your Inner Axle Shaft Oil Seals, you have to remove the brakes, hubs, axle shafts, and differential. See TSB4597 for detailed, color illustrated, easy to read service procedures for removing and installing your AAM925 Front Axle Inner Axle Shafts.

Tech Note 3: Seal Type
QU10945 is an oil bath type seal. The actual seal surface is internal, meaning the inner sleeve of the seal rotates within the outer body. With this design, the outside diameter of the seal shell is a press fit in the axle housing. The inside diameter of the rotating sleeve is an interference fit on the axle shaft. If you had to use a pry bar to get your axle shafts out, it was due to the tight fit between the axle shaft and seal.

Tech Note 4: After Installing
After installing your new seals, lubricate the inside of the rotating sleeve with a thin film of grease or petroleum jelly. Doing so will ease axle shaft installation and minimize corrosion on that axle shaft seal surface.

Tech Note 5: 2003-2013.5

Tech Note 6: 2013.5-current
2014-up RAM 2500 and 2013-up RAM 3500 4x4s have a AAM925 12 Bolt Front Axle with Electric Central Axle Disconnect. QK4685 will install the left seal on these axles, but we recomend you use our TK4038 Kit which is specific for installing both the left and right seals in the 2013-current 12 bolt axle.
Applications:
Dodge and Ram:
Ram 2500: 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014
Ram 3500: 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013
Ram 1500 Mega Cab: 2004, 2005, 2006, 2007, 2008, 2009, 2010
